DOCSIS 3.1 Cable Modem Router with WiFi 6
CODA5610
- DOCSIS 3.1 2×2 multi-carrier OFDM
- DOCSIS 3.0 32×8 channel bonding
- Switchable 5-42/5-85MHz Upstream
- 4×4 2.4GHz 802.11ax and 4×4 5GHz 802.11ax dual band concurrent MU-MIMO internal antennas
- 16 SSIDs (8 SSIDs per radio)
- Individual configuration for each SSID
- One 2.5G and two 1G Ethernet ports
- Integrated DLNA Media Server with support for video, audio and image serving
- Extensive operator control via configuration file and SNMP
- TR-069 and HNAP for easy setup and remote management
The CODA5610Q gateway is more than ready for every demanding application. Online gamine, virtual reality, 4K and 8K streaming, video conferencing…the CODA5610Q provides a flawless, stutter-free experience for it all. It supports DOCSIS 3.1 - up to 6 Gbps*. Inside-the-home networking is equally powerful, with next generation Wi-Fi 6, 2.5G ports and more. And software-switchable upstream frequency supports today and tomorrow’s return path.
- DOCSIS 3.1 2x2 OFDM/OFDMA
- DOCSIS 3.0 32x8 Channel Bonding
- Switchable 5-42/5-85MHz Upstream
- 4×4 2.4GHz 802.11ax and 4×4 5GHz 802.11ax dual band concurrent MU-MIMO internal antennas
- 16 SSIDs (8 SSIDs per Radio)
- Individual Configuration for each SSID
- DOCSIS 3.0 Compatibility
- One 2.5G and two 1G Ethernet ports
- Easy to Setup and Manage
- SNMP, TR-069 and HNAP support enable complete remote control and management.
- Integrated DLNA Media Server with support for video, audio and image serving
- Supports IPv4 and IPv6
- Management Protocol Support: TR-069, TFTP, SSHv2, SNMP v2, v3
- Supports MyHitron+, HitronCloud and OptiMy
